Video Wall, Data Wall, Multiscreen, Multi Display Controllers PDF Print E-mail



Standalone Video Wall, Multi Display Controllers

The iView video controller is designed to drive LCD, DLP screens, video wall cubes and projectors, making it perfect for all kind of display applications. To buy a large display for advertisement, for example 64 or 84 inches LCD, is too high to afford. A video wall is a group of smaller displays tiled together in a matrix to create one large display. iView Data provides the controller box that drives the display over multi-screens.




The eXtreme4s is a standalone display wall controller that accepts a single (DVI-D or HDMI) Dual Link input and can flexibly display this across four output monitors

Each output can be driven as DVI or analog RGB and can represent an arbitrary crop region of the original input image.  The ouput reslution and frame rate does not need to be related to that of the input as the eXtreme4s will optionally upscale and frame rate convert each cropped region independently.  Addionally each ouput can be independently mirrored or rotated through 90°, 180° or 270° to support creative mixes of landscape and portrait monitors.

Accepts Dual Link, Single Link DVI or HDMI, Supports both DVI and analog RGB ouput monitors.



.

PC Based Multi Screen Graphics Controllers

iView Xvision4e PCI-E Quad Channel Video Wall or Multi Screen Controller with High Performance 2D and 3D Graphics - 4 Port (x 4 lanes), RGB, SD and HD video overlay support, up to 10 cards per system - no restrictions on position or size of overlay windows.

Vigilant X-Plus - Quad Channel Video Wall Controller + Overlay. provides one overlay window per display channel. The overlays can be positioned and sized anywhere across the multi-screen display







iVwQ-MX Quad Video Processor



The iVw-Quad Video Processor is an advanced video processor for multimedia presentations. It is an ideal solution for applications where up to four video signals must be displayed on a single display.

iVwQ-MX supports 10 video inputs, of which four can be outputted simultaneously with the desired display layout through software contro
l

Click here for more info


 ALL2HDMI Converter/Scaler/Switch

iView' All-Video to HDMI Converter Scaler and Switcher.
iView All2HDMI upscales Component Video, (YPbPr), RCA, Composite Video, Scart, PC VGA (With Audio) to HDMI 1080p.

Click here for more info





NOW AVAILABLE

Video Wall, Multi Screen
Graphics Controller.

High Performace 2D and 3D Graphics

  • No restrictions on position or size of overlay windows

  • Up to 10 cards per system for a maximum of 40 displays

  • High performance DMA image load. (720MB/s



iVwQ4 4 Display Videowall


iVwQ4 4 Display, 4x DVI from 640x480 to 1920x1200, each DVI has an independent controllable display.  Can be cascaded to obtain more displays.  PIP, PAB, full screen modes and adjustable size & position.  Resize, position, flip, zoom & pan and blend output video.
